cholesky.py

#!/usr/bin/python
#
#  Copyright 2002-2018 Barcelona Supercomputing Center (www.bsc.es)
#
#  Licensed under the Apache License, Version 2.0 (the "License");
#  you may not use this file except in compliance with the License.
#  You may obtain a copy of the License at
#
#      http://www.apache.org/licenses/LICENSE-2.0
#
#  Unless required by applicable law or agreed to in writing, software
#  distributed under the License is distributed on an "AS IS" BASIS,
#  WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
#  See the License for the specific language governing permissions and
#  limitations under the License.
#

# -*- coding: utf-8 -*-

from pycompss.api.task import task
from pycompss.api.constraint import constraint
import numpy as np
from prometheus_client import CollectorRegistry, Gauge, pushadd_to_gateway

@task(returns=list)
def createBlock(BSIZE, MKLProc, diag):
    import os
    os.environ["MKL_NUM_THREADS"] = str(MKLProc)
    block = np.array(np.random.random((BSIZE, BSIZE)), dtype=np.double, copy=False)
    mb = np.matrix(block, dtype=np.double, copy=False)
    mb = mb + np.transpose(mb)
    if diag:
        mb = mb + 2 * BSIZE * np.eye(BSIZE)
    return mb


def genMatrix(A, MSIZE, BSIZE, MKLProc):
    for i in range(MSIZE):
        A.append([])
        for j in range(MSIZE):
            A[i].append([])
    for i in range(MSIZE):
        mb = createBlock(BSIZE, MKLProc, True)
        A[i][i] = mb
        for j in range(i+1, MSIZE):
            mb = createBlock(BSIZE, MKLProc, False)
            A[i][j] = mb
            A[j][i] = mb


@task(returns=np.ndarray)
def potrf(A, MKLProc):
    from scipy.linalg.lapack import dpotrf
    import os
    os.environ['MKL_NUM_THREADS'] = str(MKLProc)
    A = dpotrf(A, lower=True)[0]
    return A


@task(returns=np.ndarray)
def solve_triangular(A, B, MKLProc):
    from scipy.linalg import solve_triangular
    from numpy import transpose
    import os
    os.environ['MKL_NUM_THREADS'] = str(MKLProc)
    B = transpose(B)
    B = solve_triangular(A, B, lower=True)  # , trans='T'
    B = transpose(B)
    return B


@task(returns=np.ndarray)
def gemm(alpha, A, B, C, beta, MKLProc):
    from scipy.linalg.blas import dgemm
    from numpy import transpose
    import os
    os.environ['MKL_NUM_THREADS'] = str(MKLProc)
    B = transpose(B)
    C = dgemm(alpha, A, B, c=C, beta=beta)
    return C


@task(returns=np.ndarray)
def syrk(A, B, MKLProc):
    from scipy.linalg.blas import dsyrk
    import os
    os.environ['MKL_NUM_THREADS'] = str(MKLProc)
    alpha = -1.0
    beta = 1.0
    B = dsyrk(alpha, A, c=B, beta=beta, lower=True)
    return B


def cholesky_blocked(A, MSIZE, BSIZE, mkl_threads):
    import os
    cont = 0
    for k in range(MSIZE):
        # Diagonal block factorization
        A[k][k] = potrf(A[k][k], mkl_threads)
        cont += 1
        # Triangular systems
        for i in range(k+1, MSIZE):
            A[i][k] = solve_triangular(A[k][k], A[i][k], mkl_threads)
            A[k][i] = np.zeros((BSIZE, BSIZE))
            cont += 1
        # update trailing matrix
        for i in range(k+1, MSIZE):
            for j in range(i, MSIZE):
                A[j][i] = gemm(-1.0, A[j][k], A[i][k], A[j][i], 1.0, mkl_threads)
                cont += 1
            A[j][i] = syrk(A[j][k], A[j][i], mkl_threads)
            cont += 1
    print("Number of tasks: {}".format(cont))
    return A


def joinMatrix(A):
    joinMat = np.matrix([[]])
    for i in range(0, len(A)):
        currRow = A[i][0]
        for j in range(1, len(A[i])):
            currRow = np.bmat([[currRow, A[i][j]]])
        if i == 0:
            joinMat = currRow
        else:
            joinMat = np.bmat([[joinMat], [currRow]])
    return np.matrix(joinMat)


def cholesky():
    import time
    import sys
    from pycompss.api.api import compss_barrier

    MSIZE = int(sys.argv[1])
    BSIZE = int(sys.argv[2])
    mkl_threads = int(sys.argv[3])

    registry = CollectorRegistry()
    g = Gauge('execution_time', 'Execution time of each iteration of the given application', registry=registry)
    g.set(0)

    while True:
        # Generate de matrix
        startTime = time.time()

        # Generate supermatrix
        A = []

        genMatrix(A, MSIZE, BSIZE, mkl_threads)
        #compss_barrier()
        initTime = time.time() - startTime

        startDecompTime = time.time()
        res = cholesky_blocked(A, MSIZE, BSIZE, mkl_threads)
        compss_barrier()
        decompTime = time.time() - startDecompTime

        totalTime = decompTime + initTime

        print("---------- PARAMS ----------")
        print("MSIZE:{}".format(MSIZE))
        print("BSIZE:{}".format(BSIZE))
        print("initT:{}".format(initTime))
        print("decompT:{}".format(decompTime))
        print("totalTime:{}".format(totalTime))
        print("----------------------------")
        #time.sleep(3)
        g.set(totalTime)
        #push_to_gateway('localhost:9091', job='execTime', registry=registry)
        pushadd_to_gateway('localhost:9091', job='compss', registry=registry)
        compss_barrier()


if __name__ == "__main__":
    cholesky()
